0-B104 Beetle B104 Gearmotor 104:1 <p align="left"><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">These
are some awesome
motors for your Beetleweight (3 pound) robot, or for a steroid-powered
Antweight. Also great for applications that require high-torque lifting
or movements of arms, etc.</font></p>
<p align="left"><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">This 104:1 gear ratio is a bit slower for combat robots, but provides massive torque!</font></p>
<p align="left"><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">All-metal
planetary gearbox with metal gears. You'll be able to push your way through just about anything with a huge 247oz-in of torque! </font></p>
<p align="left"><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Check
out these numbers: </font></p>
<table width="100%" border="1" cellpadding="0" cellspacing="0" bordercolor="#666666">
<tr>
<td width="22%" rowspan="2" class="main">&nbsp;</td>
<td colspan="2" valign="bottom" class="main"><div align="center"><font color="00ff66"><b><font size="2" face="Arial, Helvetica, sans-serif">B104
model</font> </b></font></div></td>
</tr>
<tr>
<td width="11%" class="main"><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">6V</font></td>
<td width="13%" class="main"><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">12V</font></td>
</tr>
<tr>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">No
load speed </font></td>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">90rpm</font></td>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">144rpm</font></td>
</tr>
<tr>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">Amps
@ nominal</font></td>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">0.3
A</font></td>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">0.4
A</font></td>
</tr>
<tr>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">Stall
current</font></td>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">2.3
A </font></td>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">4.6
A </font></td>
</tr>
<tr>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">Stall
torque</font></td>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">155
oz-in (11,161 g-cm) </font></td>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">247
oz-in (17,786 g-cm)</font></td>
</tr>
<tr>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">Gear
ratio</font></td>
<td colspan="2" class="main"><div align="center"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">104:1</font></div></td>
</tr>
<tr>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">Weight</font></td>
<td colspan="2" class="main"><div align="center"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">2.47
oz (70g)</font></div></td>
</tr>
<tr>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">Diameter</font></td>
<td colspan="2" class="main"><div align="center"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">0.86&quot; (21.8mm)</font></div></td>
</tr>
<tr>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">Length</font></td>
<td colspan="2" class="main"><div align="center"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">2.0&quot; (50.8mm)</font></div></td>
</tr>
<tr>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">Shaft
diameter</font></td>
<td colspan="2" class="main"><div align="center"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">4
mm - with flat </font></div></td>
</tr>
<tr>
<td class="main"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">Shaft
length</font></td>
<td colspan="2" class="main"><div align="center"><font color="#CCCCCC" size="2" face="Arial, Helvetica, sans-serif">12
mm</font></div></td>
</tr>
<tr>
<td class="main"><font color="cccccc" size="2" face="Arial, Helvetica, sans-serif">Mounting Holes </font></td>
<td colspan="2" class="main"><font color="cccccc" size="2" face="Arial, Helvetica, sans-serif">Four M2 mounting holes on the gearbox face </font></td>
</tr>
</table>

Beetle B104 Gearmotor 104:1
Extreme torque from a motor that weighs less than 3 oz!

$33.49
Robot MarketPlace - Beetle B104 Gearmotor 104:1

Motors
    Small Geared Motors


Click photo to enlarge.

Beetle B104 Gearmotor 104:1
Part# 0-B104



(average customer rating)

$33.49
QTY
Currently Backordered, Check Back Soon
Stock Status: Backordered NO ETA
